BONNET C+R

03.5240US

Powerful illumination of the entire engine bay - with US plug

In stock
Shipping 1-3 Days

LINE LIGHT BONNET C+R - Powerful illumination of the entire engine bay

The new version of the bonnet light provides you with an extremely bright and powerful illumination of the entire engine bay. Compared to a traditional fluorescent bonnet light it provides 75% more luminescence.

The DUAL SYSTEM lighting functionality means the work light is both rechargeable and with 5 m rubber cable offering unlimited application possibilities and complete freedom in your daily tasks. Without cable the bonnet light might also be used as a large inspection lamp.

Supplied with an adjustable telescopic holder (1.2-1.7m) with soft-padded hook ends, this provides a firm and scratch-free grip on the vehicle. The holder is compact and takes up less space when stored away.

Inside the cabin the bonnet light may also be used as a work light either mounted by the telescopic holder or mounted onto the windscreen by the flexible arm with suction cup. Additional accessories is available to position the lamp all places on or beneath the car.

By means of a built-in prism, LINE LIGHT BONNET concentrates the light in a 75 degrees beam angle providing an extremely bright and powerful illumination of the specific working area. Blinding during work is avoided, and the lamp itself can be turned to provide the optimum lighting angle.

The LINE LIGHT BONNET C+R is made in Denmark.

Five benefits by the upgraded Bonnet Light C+R:
  • Light output (1000 lumen) increased by more than 40%
  • Dust and waterproof, IP65
  • Choose between 2 light settings (50% or 100%) for maximized operating time
  • New magnetic, electronic switch
  • Extremely low weight, only 1000g incl holder
// This work light is applicable for all kinds of work tasks at the auto workshop, construction site or other demanding working environments. For the painting industry, we offer a complete COLOR MATCH & DETAILING range that is designed for color matching, detailing and general paint work.

// The design of LINE LIGHT BONNET C+R is unique and covered by EU design patent RCD No 4070035.
Product Number
03.5240
EAN number
5708997006054
Product types
Tubelight
Net Weight (kg)
1.50
Length (mm)
1,017.00
Width (mm)
25.00
Height (mm)
25.00
Packaging
4-colour box
In the box
Lamp, charger, telescopic holder, manual
Gross weight, packaging (kg)
1.87
Length, packaging (mm)
1,140.00
Width, packaging (mm)
95.00
Height, packaging (mm)
110.00
Sales display included
No
Qty in outer box
1.00
US versioned dimensions (in)
0.98x40.43in
US versioned net weight (lb)
2.2lbs
Battery capacity (mAh)
5200
Battery type
Li-ion
Battery voltage (V)
3.70
Cable
5m 2x1mm2 H05RN-F
US versioned cable (in)
16 ft cable
Charger included
Yes
Charging input voltage (V)
100-240V AC 50/60Hz
Charging current (A)
3.50
Charging voltage DC (V)
4.20
Max Power Consumption (W)
13.00
Plug type
Type A (US plug)
Power source
Cable & Rechargeable
Adjustable Light Output
2 Levels
Beam Angle Main
75°
CCT (Kelvin)
6000
CRI
Ra > 80
Illuminance Distance (Meter)
0.50
Illuminance, Max (Lux)
2000
Illuminance, Min (Lux)
1000
Light Source
48 SMD LEDs
LED performance (lm/w)
150
Luminous Flux, Max (Lumen)
1000
Luminous Flux, Min (Lumen)
500
Charging time (hours)
4.00
Impact resistance (meter)
1.00
US versioned Impact resistance (in)
39.37in
Impact protection
IK07
Ingress protection
IP65
US versioned operating temperature (°F)
10°F to 100°F
Operating temperature
-10 °C to +40 °C
Operating time, min. brightness (hours)
4.00
Product family
LINE LIGHT
Product line
WORK LIGHTS
